1970's Snapper rear engine mower rebuild and mod log.

[OldNoob]

What color red did u use? If I recall, Krylon cherry red was a close Snapper red.

How did you get the Snapper lettering done?

It's Rustolium Cherry red
I got the decals from this link. Although the comet letters are too big.

Fits Snapper Comet 2680 Decal Kit (1973) Riding Mower

Nothing makes a piece of equipment sell faster than a fresh paint job and a set of brand-new decals. Unfortunately, new decals can be expensive and hard-to-find. That's where we come in! Here's what makes our kits better than the rest: - Our Air-Release 3M vinyl allows easy installation with...

equipmentdecals.com



[OldNoob]

The clutch chain case is rebuilt and finished. I may add a couple of more bolts to the traction wheel



[OldNoob]

Now entering the deep dark world of the differential case.



[hlw49]

Gears look in good shape. Still have one sitting in my shop may restore her some day.



[seattlepioneer]

I always thought that Snapper mower got CHEATED at the academy awards when it didn't even get a "Best Supporting Actor" NOMINATION from the Forrest Gump movie.

How long will it be before another mower gets such a featured Hollywood movie role?

I suppose I should write a screen play. Anyone have an idea for such a movie?



[OldNoob]

6 problems found in the differential case.
The "half shaft" or outgoing shaft is work out the internal bushings are worn and the outside of the shaft is worn. this is going to be kinda expensive to replace.
The internal nylon thrust washer is worn out as well as the metal washers for the hexagonal shaft.
The o-rings and cupped belville washers are missing from the large sprocket shaft.
The smaller sprocket on the hexagonal shaft is loose ( this will be a expensive replacement unless i can figure out a way to repar this myself.)
The chain is worn out
The case has a chain groove wore into it due to the lack of washers, but not all the way through but very close to breaking through. (This will be very expensive if i have to replace it.)



[OldNoob]

Any ideas for a cleaning this grease off? i dont have a parts washer or a pressure washer. i was thinking maybe paint thinner? or something cheaper?



[slomo]

Dude, for tired old greasy oily gunk removal, Diesel and an old paint brush. Well now it's 5 bucks a gallon thanks to Brandon Biden. We can all thank the voters who voted for that puppet. Or that stolen election. Back on topic, best stuff to use and normally cheap.



[slomo]

If you want it clean without YOU cleaning them, toss that case in your wife's dishwasher. Put on hot pot scrubber mode. Sucker will come out ready to eat off of. Every house in America has a darn good parts washer in the kitchen.



[7394]

Forget the clean & pack it full of grease & reassemble..
