Briggs V Twin 22HP oil leak under both cylinder heads

[Freddie21]

Another trick is to lightly coat the area with flour. It is magnify the leak spot.



[Johner]

Need help figuring out where my oil leak is coming from. Its coming from above the sump gasket so I don't believe its that. Its running down the fins of both heads and drips off the bottom of the heads near the exhaust ports. It's not the valve cover gaskets because I made sure they were sealed. The only thing I can think it might be is head gaskets. I looked over the sump gasket seam and it looks good and dry. Should I just start tearing off the heads? What else could it be?

Looks like an exhaust gasket is bad.



[melvin1942]

Need help figuring out where my oil leak is coming from. Its coming from above the sump gasket so I don't believe its that. Its running down the fins of both heads and drips off the bottom of the heads near the exhaust ports. It's not the valve cover gaskets because I made sure they were sealed. The only thing I can think it might be is head gaskets. I looked over the sump gasket seam and it looks good and dry. Should I just start tearing off the heads? What else could it be?

Have you checked the head to see if it is flat. It could be warped. Also check the block.



[Scrubcadet10]

problem was solved.
