Starts fine, idles well, bogs down when turning on PTO.

[bobknowverylittle]

Snapper Pro S200xt, 49E877 vanguard engine EFI system. As mentioned, engine bogs down when turning on the PTO. Just started doing that two cuts ago. Turned off engine to check for debris and or bad pulley, they were fine. Started engine again and problem went away, cut grass. Same thing happen again following week, again stop and restarted engine and all worked fine. This week problem has come back and is not going away as before. Plugs have only 28 hrs. , all pulleys were not hot to the touch. Any suggestions on what to check? M.I.L. comes on and then off again, just not getting full throttle when PTO engaged.



[slomo]

engine bogs down when turning on the PTO

I'd look a the PTO and the electrical circuit.

M.I.L. comes on and then off again

What code is it throwing?

just not getting full throttle when PTO engaged.

Need to investigate this.



[Auto Doc's]

The conditions favors a fuel starvation. This usually begins at the fuel tank pickup tube.



[bobknowverylittle]

I'd look a the PTO and the electrical circuit.

What code is it throwing?

Need to investigate this.



[bobknowverylittle]

Don't have any code panel, that i know of. Unless it appears on hour gauge when happening. Went to see if anything on hour gauge and could not get it to fail today? Feel certain it will show up again!



[Auto Doc's]

From what I have studied so far, these have issues with "smart" ignition coils failing. The right side usually fails first, but both coils are recommended to be replaced, especially if it has considerable hours on the machine. These have a warning light that will stay on steady when running or flash a code with just the key turned on.

I have not found a code list anywhere yet.

The first things to do is inspect all wiring and connection really well, then loosen clean and retighten any grounds starting at the battery. Troubleshooting 101, that many overlook.
