MTD Seat Spring Switch photo(s) please

paulbaker1954

Forum Newbie
Joined
Sep 27, 2023
Threads
4
Messages
8
Can anyone post some pictures of how the old style MTD seat safety switch (parts 17 and 18) in attached are fitted.

Mower I just bought has them removed and I want to reinstate them but not sure how they are fitted/operate


Attachments

  • IMG_2816.png
    526.5 KB · Views: 3

StarTech

Lawn Pro
Top Poster Of Month
Joined
Feb 19, 2020
Threads
70
Messages
9,804
See if this helps...One black plastic and two white plastic insulators. Note: Wire colors can be different.
